Alcatel Vacuum Technology France --- IPUP A100 Instruction manual
Monitoring system function table
IPUP A100L version
MANAGEMENT MENU, OPERATING TIME, LAST TEN WARNINGS, LAST TEN HAZARDS
SET
ENTER ENTER
Initial configura-
tion
ENTER
+
MANAGEMENT PASSWORD 0 to 65535
M
A
N
A
G
E
M
E
N
T
VERSION FRAME SERIAL N°
M40 SERIAL N°
M40 OTP VERSION
M40 FLASH VERSION
ADP 100 SERIAL N°
OTP DISP. VERSION
FLASH DISP. VERSION
STORAGE ENABLED/DIS-
ABLED
DIS-
ABLED
CONFIG SAVE Save the pump configuration into the remote display
memory. Valid by pressing Enter Key.
CONFIG LOAD Allow to transfer the remote display memory into the
pump memory. Valid by pressing Enter Key.
OPERATING TIME Displays the operating times of the various components.
LAST WARNING(S) Displays the 10 last recorded warnings.
LAST ALARM(S) Displays the 10 last recorded hazards.
