ALDI Workzone Titanium Xfinity Series User Manual

6
6
AFTER SALES SUPPORT
1300 889 028 (toll free)
MODEL No.:
CSC165XA.9 • 2323 • 05/2019
e-mail:
info.aldi@positecgroup.com
3. Parts description
1. Lock-O Button
2. Trigger Switch
3. Front Handle
4. Spindle Lock Button
5. Base Plate Angle Scale
6. Base Plate Bevel Lock Knob
7. Parallel Guide Lock Knob
8. Cutting Mark - 45°
9. Cutting Mark - 0°
10. Parallel Guide
11. Base Plate
12. Lower Guard Lever
13. Lower Blade Guard
14. Fixed Guard
15. Dust Extraction Adapter
16. Battery Pack
17. Battery Pack Release Button
18. Inner Flange (See Fig. B3)
19. Saw Blade
20. Outer Flange (See Fig. B3)
21. Blade Bolt (See Fig. B3)
22. Cutting Depth Scale (See Fig. C)
23. Cutting Depth Lock Knob (See Fig. C)
24. Hex key (See Fig. K)
25. Blade rotation indicator
26. Main handle
27. Spindle
28. Parallel guide notches

ALDI Workzone Titanium Xfinity Series Specifications

General

Brand	ALDI
Model	Workzone Titanium Xfinity Series
Category	Power Tool
Language	English
