Alesis STRIKE - Features; Top Panel

4
Features
Top Panel
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1. Display: This full-color display shows the current kit, settings, and other information. Use the cursors
to move through the menus and lists shown here. Use the Data Dial to scroll through available options.
Use the Function Buttons (F1–F6) to select tabs shown at the bottom edge of the display.
2. Function Buttons (F1–F6): Press one of these 6 buttons to select the corresponding tab shown above
it (at the bottom edge of the display).
3. Data Dial: Turn this dial to scroll through available options shown in the display.
4. Cursors: Use these buttons to select different areas shown in the current page in the display.
5. Enter: Press this button to confirm a selection shown in the display.
6. Kit: Press this button to enter the Kit menu (the default view when you power on the drum module).
7. Main Vol: Turn this knob to adjust the volume level of the Main Out on the rear panel. This level is
independent from the volume level of each voice or the overall kit.
8. Aux In: Turn this knob to adjust the volume level of the Aux In on the rear panel. This also controls the
input recording level of Sample Mode.
9. Headphone Out (1/4”/6.35 mm): Connect your stereo headphones to this input. Adjust the volume with
the Headphone Vol knob.
10. Headphone Vol: Turn this knob to adjust the volume level of the Headphone Out.
11. Sliders: Use these sliders to adjust the independent volume level of each sound in your current kit. The
sound’s name is shown under the slider.
