Alfa Network N2 - Introduction and Hardware Overview; Hardware Description

3
INTRODUCTION
The N2 is a 2x2 MIMO IEEE 802.11b/g/n wireless outdoor AP/CPE which support
data rates up to 300Mbps. It is rain and splash proof when install in upright position.
N2 also integrated 14dBi patch antenna and passive PoE for simplify installation.
HARDWARE DESCRIPTION
Below are N2 hardware descriptions
①
②
③
① PoE LAN
② PoE WAN (in Rouer mode )
PoE LAN (in Bridge Mode)
③ Reset
L-Mount (Option)
Pole Mount Holders
Wall Mount Hole
Wall Mount Hole
LED Indicator
