Timy3 - General
-37-
12.2 RS485 Interface
This interface is only used for special applications such as wind speed measurement, Timy3
Terminal etc.
12.3 Interface for Display Board
Output format: 1 start bit, 8 data bits, no parity bit, 1 stop bit
Bit rate: factory setting: 2400 baud (for ALGE-TIMING GAZ display board)
2400, 4800, 9600, 19200, 28800, 38400
Transmission protocol: ASCII
NNN.xxxxxxxxM:SSxxxx(CR) ............... running time (without 1/10 seconds)
NNN.xxxxHH:MM:SSxxxx(CR) ............... running time (without 1/10 seconds)
NNN.xxxxHH:MM:SS.zxx(CR) ............... running time (with 1/10 seconds)
NNNCxxxxHH:MM:SS.zhtRR(CR)........... channel C1 finish time with rank
NNNCxxxxHH:MM:SS.zhtxx(CR) ........... channel C1 finish time without rank
NNNDxxxxHH:MM:SS.zhtRR(CR) ........... channel C1 total time with rank
NNNDxxxxHH:MM:SS.zhtxx(CR)........... channel C1 total time without rank
NNNAxxxxHH:MM:SS.zhtRR(CR)........... channel C2 1. intermediate time
NNNBxxxxHH:MM:SS.zhtRR(CR)........... channel C3 2. intermediate time
NNNExxxxHH:MM:SS.zhtRR(CR)........... channel C4 3. intermediate time
NNNFxxxxHH:MM:SS.zhtRR(CR)........... channel C5 4. intermediate time
NNNGxxxxHH:MM:SS.zhtRR(CR)........... channel C6 5. intermediate time
NNNHxxxxHH:MM:SS.zhtRR(CR)........... channel C7 6. intermediate time
NNNIxxxxHH:MM:SS.zhtRR(CR)........... channel C8 7. intermediate time
NNNSxxx©xxxxsxss.ssxRR(CR)........... speed
NNN ....................... start number (hundreds, tens, ones - digit 1 to 3)
. ............................ point on the fourth digit is the identification for a running time
HH:MM:SS.zht ....... time in hours, minutes, seconds and 1/1000 seconds
© ............................ speed measurement: output of following ASCII signs: 01 hex for km/h, 02
hex for m/s, 03 hex for mph
RR .......................... rank
x ............................. blank
(CR) ....................... carriage return
13 USB Interface
Currently possible applications for USB interface:
• update the Timy3 software with installation manager or Timy3 USB program
• query and change of settings (as RS232)
• recording of times with program ComtoFile
• evaluation with program Time.NET
• evaluation with program Excel Writer
