Technical overview
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working
inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Inside view of your computer
1. power-supply unit 2. optical-drive assembly
3. top cover 4. top-chassis fan
5. system board 6. processor fan and heat-sink assembly
7. graphics card 8. right-side cover
