Replacing the right-side cover
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working
inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Connect the lighting cable to the right-side cover.
a. chassis
b. lighting cable
c. right-side cover
d. tabs
e. slots
2. Align the tabs on the right-side cover with the slots on the chassis and snap the right-side cover to lock it in place.
21
