Processor liquid-cooling assembly
Removing the processor liquid-cooling assembly
Prerequisites
1. Follow the procedure in Before working inside your computer.
WARNING: Despite having a plastic shield, the processor liquid-cooling assembly may be very hot during normal
operation. Ensure that it had sufficient time to cool before you touch it.
CAUTION: To ensure maximum cooling for the processor, do not touch the heat transfer areas on the processor
liquid-cooling assembly. The oils in your skin can reduce the heat transfer capability of the thermal grease.
2. Remove the left-side cover.
3. Remove the top-cover.
4. Remove the right-side cover.
5. Remove the memory modules.
About this task
The following images indicate the location of the processor liquid-cooling assembly and provides a visual representation of the
removal procedure.
36
