Right tron-light board
Removing the right tron-light board
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left-side cover.
3. Remove the top-cover.
4. Remove the right-side cover.
About this task
The following images indicate the location of the right tron-light board and provides a visual representation of the removal
procedure.
Steps
1. Disconnect the tron-light cable.
2. Remove the four screws (#6-32) that secure the right tron-light board to the chassis.
3. Remove the right tron-light board off the chassis.
34
