22 | About your monitor
Universal Serial Bus (USB) interface
This section gives you information about the USB ports that are available on the
monitor.
Transfer speed Data rate Power consumption*
Super-Speed 5 Gbps 4.5 W (Max, each port)
High speed 480 Mbps 4.5 W (Max, each port)
Full speed 12 Mbps 4.5 W (Max, each port)
NOTE: This monitor is Super-Speed USB 3.0 compatible.
* Up to 2 A on USB downstream port (with battery icon) with battery
charging version-compliant devices or normal USB
devices.
USB upstream connector
Pin number 9-pin side of the
connector
1 VCC
2 D-
3 D+
4 GND
5 SSTX-
6 SSTX+
7 GND
8 SSRX-
9 SSRX+
