About your monitor | 23
USB downstream connector
Pin number 9-pin side of the
connector
1 VCC
2 D-
3 D+
4 GND
5 SSRX-
6 SSRX+
7 GND
8 SSTX-
9 SSTX+
USB ports
• 1 x upstream - bottom
• 4 x downstream - bottom (2) and side (2)
Power charging port - the port with
icon; supports up to 2 A fast-
charging capability if the device is BC1.2 compatible.
NOTE: USB 3.0 functionality requires a USB 3.0-capable computer.
NOTE: The USB ports on the monitor work only when the monitor is
turned on or in power save mode. If you turn off the monitor and then
turn it on, the attached peripherals may take a few seconds to resume
normal functionality.
OLED monitor quality and pixel policy
During the OLED monitor manufacturing process, it is not uncommon for one or
more pixels to become fixed in an unchanging state, which are hard to see and
do not affect the display quality or usability. For more information on OLED
Monitor Quality and Pixel Policy, see www.dell.com/support/monitors.
