Alienware M18x R2 User Manual

System Setup | 101
Advanced Menu—Performance Options
Allows you to enable or disable the global
overclocking feature.
• Disabled: The overclocking feature is
disabled.
• Enabled: Displays additional overclocking
options.
Non-Turbo Flex Support Allows you to modify the CPU flex ratio with
Turbo Mode disabled.
Flex Ratio Override Appears when Non-Turbo Flex is enabled and
allows you to specify the flex ratio for all CPU
cores.
Extreme Edition Allows Extreme Edition CPUs to adjust the flex
ratio in a Turbo Mode environment that allows
each individual core ratio to be modified.
Extreme Edition Core Ratio
Limits
Allows you to modify the flex ratio of individual
cores physically present in the CPU.
Memory Override Support Allows you to enable or disable the memory
override option support.
• Disabled: The memory override support is
disabled.
• Enabled: Displays additional memory override
support options.
Memory Voltage Allows you to modify memory voltage.
Memory Frequency Allows you to modify memory frequency.
DIMM Profile (XMP) Allows you to configure different XMP options.
Override Turbo Settings Allows you to override CPU Turbo Mode settings.
Long Duration PWR Limit Allows you to specify the Turbo Mode power limit
1 in Watts.
Indicates the time window over which TDP value
should be maintained. A value of 0 programs this
value to the fused limit.
Short Duration PWR Limit Power Limit 1 time value in seconds.
Short Duration Turbo Mode Power Limit 2 value in Watts.
PWR Limit A value of 0 programs this value to 1.25 x TDP.
Book.book Page 101 Thursday, April 19, 2012 2:38 PM

Alienware M18x R2 Specifications

General

Tcase	- °C
Bus type	DMI
Tjunction	105 C °C
FSB Parity	No
Processor cache	6 MB
Processor cores	4
Processor model	i7-3610QM
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3600 Mobile series
Processor socket	Socket G2
Processor threads	8
Processor codename	Ivy Bridge
Number of QPI links	-
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Configurable TDP-down	- W
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	23
Maximum number of PCI Express lanes	16
CUDA	Yes
On-board graphics card ID	0x166
Discrete graphics card model	NVIDIA® GeForce® GTX 660M
On-board graphics card model	Intel® HD Graphics 4000
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	- GB
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Processor ARK ID	64899
Processor package size	37.5 x 37.5 (rPGA988B) mm
CPU configuration (max)	1
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Form factor	Clamshell
Product type	Laptop
Product color	Black
Market positioning	Gaming
Motherboard chipset	Intel HM77
Memory slots	4x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Disc types supported	CD, DVD
HDD size	2.5 \
HDD speed	7200 RPM
HDD interface	SATA III
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	750 GB
Compatible memory cards	MMC, MMC+, MS PRO, Memory Stick (MS), SD, SDHC, SDXC
Display surface	Gloss
Display diagonal	18.4 \
Native aspect ratio	16:9
Video capturing speed	30 fps
Front camera resolution (numeric)	2.1 MP
Audio system	HD
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	3.0+HS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Home Premium
Battery capacity	97 Wh
Battery life (max)	- h
Number of battery cells	12
AC adapter power	240 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	12.3 A
AC adapter output voltage	19.5 V
Operating shock	110 G
Operating altitude	-15.2 - 3048 m
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Non-operating vibration	1.3 G
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	322.5 mm
Width	436 mm
Weight	5410 g
Height (rear)	54.7 mm
Height (front)	53 mm
