Alienware M18x R2

Removing the Coin-Cell Battery | 19
Procedure
1 Disconnect the coin-cell battery cable from the connector on the system board.
2 Remove the coin-cell battery cable from the routing guides on the computer base.
3 Pry up the coin-cell battery from the slot on the system board.
1 coin-cell battery cable connector 2 coin-cell battery
2
1
