20 | Replacing the Coin-Cell Battery
Replacing the Coin-Cell
Battery
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
"Before You Begin" on page 9. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
Procedure
1 Place the coin-cell battery into the slot and press gently to adhere it to the computer
base.
2 Route the coin-cell battery cable through the routing guides on the computer base.
3 Connect the coin-cell battery cable to the connector on the system board.
Postrequisites
1 Replace the base cover. See "Replacing the Base Cover" on page 15.
2 Replace the battery pack. See "Replacing the Battery Pack" on page 13.
3 Follow the instructions in "After Working Inside Your Computer" on page 11.
10
