Removing the Processor Heat-Sink | 79
Procedure
1 In sequential order (indicated on the processor heat-sink), loosen the captive screws
that secure the processor heat-sink to the system board.
2 Carefully lift the processor heat-sink out of the computer base.
1 captive screws (4) 2 processor heat-sink
1
2
