50 | Removing the Palm Rest
Procedure
1 Disconnect the power-button board cable, status-light board cable, speaker-LED
board cable, and touchpad cable from the connectors on the system board.
1 power-button board cable
connector
2 status-light board cable
connector
3 speaker-LED board cable 4 touchpad cable connector
1
2
3
4
