About VHF Marine channels
This marine radio can operate on all international, USA and Canadian
VHF marine channels. Be mindful to operating channels according to the
location of your vessel. Use of incorrect channels, useless transmissions
and harmful inteferences on marine channels may be subject to penalty
and/or ne by local authority. Weather channels and alert functions are
usable where N.O.A.A. weather radio signals are receivable.
Please read this manual completely from the rst page to the last, to
learn all the functions the product oers. It is important to note that
some of the operations may be explained in relation to information in
previous chapters. By reading just one part of the manual, you may
risk not understanding the complete explanation of the function.
Before transmitting
There are many radio stations operating in proximity to the frequency
ranges this product covers. Be careful not to cause interference when
transmitting around such radio stations.
■
Electromagnetic Interference/Compatibility
During transmissions, your radio generates RF energy that can possibly
cause interference with other devices or systems. To avoid such interfer-
ence, turn o the radio in areas where signs are posted to do so.
■
DISTRESS CALL PROCEDURE (GPS, MMSI registration
and preprogramming required.)
1. Open the red key cover, press and hold [DISTRESS] key for 5 sec-
onds. The channel changes to CH70, Beep sounds 5 times and trans-
mits a distress call.
2. Wait for an acknowledgment (ACK) on Channel 70. It automatically
retries the call until ACK signal is received.
• After the ACK is received, the channel changes to CH16 automatically.
3. Press [PTT] and call MAYDAY 3 times, name of your vessel and na-
ture of distress and request of assistance.
■
Emergency Calling Procedure on CH16
If your DR-MX15 is not equipped with GPS receiver (without DSC
setting) and in case your vessel requires assistance, contact other
vessels and the appropriate Coast Guard by sending a distress call on
Channel 16.
Set the 16CH and:
1. Call “MAYDAY” 3 times.
2. “THIS IS (name of your vessel)”
3. Your call sign or other identication of the vessel if any.
4. “LOCATED AT (your position)”
5. The nature of the distress and assistance required.
6. Any other information which might facilitate the rescue.
■ Ultra compact, Output power selectable 25W/1W
■ Waterproof IPX7
■ Dual-watch/Tri-watch Function
■ DSC built-in
■ Various scan modes, Key lock
■ Weather Alert Function
■ Bright LCD and easy-to-operate backlit
■ Position Indication on display (Optional GPS receiver
required)
Features
To prevent any hazard during operation of Alinco’s radio product, in this
manual and on the product you may nd symbols shown below. Please
read and understand the meanings of these symbols before starting to
use the product.
WARNING
Danger
This symbol is intended to alert the user to an
immediate danger that may cause loss of life and
property if the user disregards the warning
.
Alert
This symbol is intended to alert the user to a
possible hazard that may cause loss of life and
property if the user disregards the warning.
Caution
This symbol is intended to alert the user a
possible hazard that may cause loss of property
or injure the user if the warning is disregarded.
Alert symbol. An explanation is given
.
Warning symbol. An explanation is given.
Instruction symbol. An explanation is given.
ALERT
Environment and condition of use
Environment and condition of use
DO NOT use or place the radio in direct sunlight or in areas with tempera-
tures range of below –20°C or above +55°C. Be mindful to keep the radio
warm in extremely cold place as low temperature may temporary cause the
drop of voltage to batteries.
Do not use this product in close proximity to other electronics devices,
especially medical ones. It may cause interference to those devices.
Keep the radio out of the reach of children
.
In case a liquid leaks from the product, do not touch it. It may damage your
skin. Rinse with plenty of cold water if the liquid contacted your skin.
Never operate this product in facilities where radio products are prohibited for
use such as aboard aircraft, in airports, within or near the operating area of
business wireless stations or their relay stations.
Do not use multiple radios in very close proximity. It may cause interference
and/or damage to the product(s).
The manufacturer declines any responsibilities against loss of life and
property due to a failure of this product when used with or as a part of a
device made by third parties.
Use of third party accessory may result in damage to this product. It will void
our warranty for repair.
The manufacturer declines any responsibilities against loss of life and/or
property by missing contacts due to failure of this product.
A license may be required to operate this device.Please consult with your
dealer about radio laws and regulations before purchase.
