PIN59
GND
-
Ground
PIN60
GND
-
Ground
PIN61
B16_L1_N
F14
3.3V
PIN62
NC
-
-
PIN63
B16_L1_P
F13
3.3V
PIN64
NC
-
-
PIN65
B16_L4_N
E14
3.3V
PIN66
NC
-
-
PIN67
B16_L4_P
E13
3.3V
PIN68
NC
-
-
PIN69
GND
-
Ground
PIN70
GND
-
Ground
PIN71
B16_L6_N
D15
3.3V
PIN72
NC
-
-
Board to Board Connectors CON2
The 80-pin female connection header CON2 is used to extend the normal
IO of the BANK13 and BANK14 of the FPGA. The voltage standards of both
BANKs are 3.3V.
Pin Assignment of Board to Board Connectors CON2
CON1
Pin
Signal Name
FPGA
Pin
Voltage
Level
CON1
Pin
Signal Name
FPGA Pin
Voltage
Level
PIN1
B13_L16_P
W15
3.3V
PIN2
B14_L16_P
V17
3.3V
PIN3
B13_L16_N
W16
3.3V
PIN4
B14_L16_N
W17
3.3V
PIN5
B13_L15_P
T14
3.3V
PIN6
B13_L14_P
U15
3.3V
PIN7
B13_L15_N
T15
3.3V
PIN8
B13_L14_N
V15
3.3V
PIN9
GND
-
Ground
PIN10
GND
-
Ground
PIN11
B13_L13_P
V13
3.3V
PIN12
B14_L10_P
AB21
3.3V
PIN13
B13_L13_N
V14
3.3V
PIN14
B14_L10_N
AB22
3.3V
PIN15
B13_L12_P
W11
3.3V
PIN16
B14_L8_N
AA21
3.3V
PIN17
B13_L12_N
W12
3.3V
PIN18
B14_L8_P
AA20
3.3V
PIN19
GND
-
Ground
PIN20
GND
-
Ground
PIN21
B13_L11_P
Y11
3.3V
PIN22
B14_L15_N
AB20
3.3V
PIN23
B13_L11_N
Y12
3.3V
PIN24
B14_L15_P
AA19
3.3V
PIN25
B13_L10_P
V10
3.3V
PIN26
B14_L17_P
AA18
3.3V
PIN27
B13_L10_N
W10
3.3V
PIN28
B14_L17_N
AB18
3.3V
PIN29
GND
-
Ground
PIN30
GND
-
Ground
PIN31
B13_L9_N
AA11
3.3V
PIN32
B14_L6_N
T20
3.3V
