Part 2.5: QSPI Flash
The FPGA core board AC7100B is equipped with one 128MBit QSPI
FLASH, and the model is N25Q128, which uses the 3.3V CMOS voltage
standard. Due to the non-volatile nature of QSPI FLASH, it can be used as a
boot device for the system to store the boot image of the system. These
images mainly include FPGA bit files, ARM application code, core application
code and other user data files. The specific models and related parameters of
QSPI FLASH are shown in Table 2-5-1.
Position
Model
Capacity
Factory
U8
N25Q128
128M Bit
Numonyx
Table 2-5-1: QSPI FLASH Specification
QSPI FLASH is connected to the dedicated pins of BANK0 and BANK14 of
