Allen-Bradley 1734-OB8S - Configuration Assemblies

Rockwell Automation Publication 1734-UM013C-EN-P - August 2010 147
I/O Assemblies Appendix E
Configuration Assemblies
Refer to the appropriate table for 1734-IB8S or 1734-OB8S configuration
assembly data.
Instance
Hex (decimal)
Module Byte Field Class
(hex)
Instance
(decimal)
Attribute
(decimal)
360 1734-OB8S 0 Safety Output Latch Error Time (low byte) 3B 0 8
1 Safety Output Latch Error Time (high byte)
2 Safety Output 0 Channel Mode 3B 1 6
3 Safety Output 1 Channel Mode 2
4 Safety Output 2 Channel Mode 3
5 Safety Output 3 Channel Mode 4
6 Safety Output 4 Channel Mode 5
7 Safety Output 5 Channel Mode 6
8 Safety Output 6 Channel Mode 7
9 Safety Output 7 Channel Mode 8
10 Dual-channel Safety Output 0 Mode 3F 1 3
11 Dual-channel Safety Output 1 Mode 2
12 Dual-channel Safety Output 2 Mode 3
13 Dual-channel Safety Output 3 Mode 4
