Allen-Bradley 1734-OB8S - Appendix D; Introduction

Rockwell Automation Publication 1734-UM013C-EN-P - August 2010 139
Appendix D
Specifications
Introduction
Refer to the appropriate module specifications as necessary.
Topic Page
1734-IB8S and 1734-OB8S Physical Specifications 139
1734-OB8S - Technical Specifications 140
1734-IB8S and 1734-OB8S - Technical Specifications 141
1734-IB8S and 1734-OB8S Physical Specifications 141
1734-IB8S and 1734-OB8S Environmental Specifications 142
1734-IB8S and 1734-OB8S Certifications 143
Table 5 - 1734-IB8S Technical Specifications
Attribute Value
Safety Input
Inputs per module 8
Input type Current sinking
Voltage, on-state input 11…30V DC
Voltage, off-state input, max 5V DC
Current, on-state input, min 3.3 mA
Current, off-state, max 1.3 mA
IEC 61131-2 (input type) Type 3
Reaction time <16.2 ms
