20 SSI Servo Module
Publication
1756-IN595A-EN-P - March 2004
You must remove the RTB before removing the module.
Figure 16 Removing the RTB
Removing the Module
Figure 17 Removing the Module
20855–M
2. Open the RTB door and pull
the RTB off the module.
1. Unlock the locking tab at
the top of the module.
42517
1. Push in top and bottom locking tabs. 2. Pull module out of the chassis.
20856–M 20857–M
