SSI Servo Module 5
Publication
1756-IN595A-EN-P - March 2004
Identifying Module Components
You received two components with your order:
• 1756-M02AS module
• RTB door label
If you did not receive these components, contact your Rockwell Automation
representative.
This module mounts in a 1756 chassis and uses a separately-ordered RTB or a
Bulletin 1492 Interface Module (IFM)
(1)
to connect all field-side wiring. This
module uses one of the following RTBs:
• 1756-TBCH 36 position Cage clamp RTB
• 1756-TBS6H 36 position Spring clamp RTB
Use an extended-depth cover (1756-TBE) for applications with heavy gauge
wiring or requiring additional routing space. When using an IFM, consult the
documentation that came with it to connect wiring.
(1)
The ControlLogix system has been agency certified using only the ControlLogix RTBs (i.e. 1756-TBCH,
1756-TBNH, 1756-TBSH and 1756-TBS6H). Any application that requires agency certification of the
ControlLogix system using other wiring termination methods may require application specific approval
by the certifying agency.
IMPORTANT
Before you install your module, you should:
• install and ground a 1756 chassis and power supply.
• order and receive an RTB or IFM, and its components, for
your application.
