Recorder Hardware
Chapter 2
22
Table 2.A
Data
Cartridge Recorder Switches
Name Function
POWER ON/OFF
T
oggle switch. T
urns recorder power on or of
f.
BAUD RA
TE
Rotary switch. Selects 300, 600, 1200, 2400, 4800 or 9600 baud
operation.
TRACK SELECT
Rotary switch. Selects track 1, track 2, or continuous operation.
READ FROM T
APE
Momentary action pushbutton switch. Puts the recorder into the READ
mode.
RECORD ON T
APE
Momentary action pushbutton switch. Puts the recorder into the
WRITE mode.
STOP/REWIND
Momentary action pushbutton switch. Used to exit READ or WRITE
mode. When the tape is stopped, the switch initiates a rewind to the
Beginning Of T
ape (BOT) mark.
Table 2.B
Data Cartridge Recorder Indicators
Name Indication
POWER
Power is applies to the recorder and the toggle switch is in the ON
position.
STOP/REWIND T
ape is repacking or rewinding.
BOTH TRACKS USED
TRACK SELECT switch is in CONT position and current operation
(READ, WRITE or IDLE) is on track 2.
END OF TRACK
T
ape has reached the end of track 1 or track 2. Illuminates between
tracks and at the end of track 2 in continuous operation.
DAT
A IN
Recorder is receiving data.
DAT
A ERROR
Recorder has failed an attempted operation.
DAT
A OUT
Recorder is transmitting data.
RECORD ON T
APE
Recorder is in the WRITE mode.
WRITE INHIBITED
Data cartridge is protected. Data can not be recorded.
READ FROM T
APE
Recorder is in the READ mode.
The data cartridge recorder includes a 230V AC fuse kit for conversion to
230V AC operation. The fuse kit includes:
Instructions for converting to 230V AC operation
A 230V, 0.25A fuse
A 230V AC label
The recorder does not come with a 230V AC power cord. Therefore, the
power cord must be changed for 230V AC operation.
230 V Fuse Kit
