Operation
Chapter 4
422
NOTE: If the recorder is turned off while a tape rewind operation is in
progress, the data on the tape will be altered.
6. Select the KYBD (keyboard) mode.
7. Enter the following command through the keyboard: AL,RL,CA].
8. Wait for the READ FROM TAPE indicator to turn on. After a short
delay the DATA OUT indicator turns on.
Wait for tape motion to stop. Both indicators should be off.
Use the following procedure to record executive programs from the
control’s memory.
1. Install the recorder as described in chapter 3.
2. Set the BAUD RATE switch to 9600 baud. Set the TRACK switch
to track 1 or track 2.
3. Set the power ON/OFF switch to the ON position.
4. Be sure that the write protect tab on the data cartridge is positioned
to the left, and insert the cartridge into the recorder.
5. Wait for the recorder to complete the repacking operation.
NOTE: If the recorder is turned off while a tape rewind operation is in
progress, the data on the tape will be altered.
6. Halt the processor.
7. Select and clear the P-register.
8. Set the P-register to octal 6.
9. Press STORE.
10. Press PRESET.
11. Press RUN.
12. Enter the following command through the keyboard: PC]. If only a
position of memory is to be stored enter the command: PC, start,
end]. “Start” and ’end” are the memory addresses between which the
data is located.
NOTE: If PC] or PC, ST, END] gives a * indication, the executive does
not have cartridge capability.
13. Wait for the RECORD ON TAPE indicator to turn on. After a short
delay the DATA IN indicator turns on.
Recording Series 8200 CNC
Executive Programs
