Allen-Bradley 1770-SB User Manual

Chapter
5
51
Maintenance
When the data cartridge recorder needs repair, contact your local
Allen-Bradley Customer Support Services Center. Only routine preventive
maintenance should be performed by the user. This section describes this
preventive maintenance.
After every ten hours of operation, clean the read/record and erase heads
(Figure 5.1) with cotton swabs dipped in a magnetic header cleaner
solvent. Also, clean the drive roller in the same manner. Do not touch the
heads with fingers or other foreign objects which may damage the head.
Figure 5.1
Data
Cartridge Recorder Magnetic Heads
Head
Drive
Roller
POWER
STOP REWIND
BOTH END OF
TRACKS USED TRACK
IN ERROR OUT
DATA
WRITE
INHB
RECORD
ON
TAPE
READ
FROM
TAPE
ON
OFF
DATA CARTRIDGE RECORDER
TRACK
SELECT
BAUD
RATE
1
2
CONT
300
600
1200
2400
4800
9600
CONTROLLER
EQUIPMENT
115V 5060 HZ
3 AMP
5A SB
3 AG
10013
General
Head Cleaning
