Allen-Bradley 1770-SB - Loading PLC-3 Programs

Operation
Chapter 4
410
16. When finished recording, remove the data cartridge and position the
record protect tab to the right.
Use the following procedure to load a recorded program into PLC-3
memory:
1. Install the recorder as described in chapter 3.
2. Set the BAUD RATE switch to 9600 baud. Set the TRACK
SELECT switch to the continuous (CONT) position.
3. Set the power ON/OFF switch to the ON position.
4. Insert a data cartridge into the recorder.
5. Wait for the recorder to complete the repacking operation .
6. Place the PLC-3 in the PROGRAM LOAD mode.
7. Type [L][O][A][D][ENTER] on the industrial terminal keyboard.
8. If tape and file names are known respond to prompts for them.
Otherwise press [ENTER] and allow the recorder to process the tape
and file names and display them on the industrial terminal CRT
monitor.
9. Respond to the prompt APPEND? by typing [Y][ENTER] on the
industrial terminal keyboard to add the recorded information to
existing information in memory or by typing [N][ENTER] on the
industrial terminal keyboard to replace the existing information with
the recorded information.
NOTE: If the file contains memory area 2 (module status) you must
select append.
10. If another file is to be loaded, respond to the next prompt with the
next file name.
11. After all files are loaded, type [E][ENTER] on the industrial terminal
keyboard.
Loading PLC3 Programs
