Operation
Chapter 4
423
Wait for tape motion to stop. Both indicators should be off.
NOTE: If the recorder stops unexpectedly and either the DATA IN or
RECORD ON TAPE indicator is on in addition to the ERROR indicator,
turn the recorder off and then on again. Press the READER RESET key.
Repeat the recording operation.
14. If the error indicator turns on during program transfer, program data
has been altered. you must repeat the recording operation.
15. Remove the data cartridge and position the record protect tab to the
right.
Use the following procedure to load an executive program from data
cartridge:
1. Install the recorder as described in chapter 3.
2. Set the BAUD RATE switch to 9600 baud. Select the track
containing the desired program.
3. Set the power ON/OFF switch to the ON position.
4. Insert the data cartridge into the recorder.
5. Wait for the recorder to complete the repacking operation .
NOTE: If the recorder is turned off while a tape rewind operation is in
progress, the data on the tape will be altered.
6. Half the processor.
7. Select and clear the S-register.
8. Set the DATA SELECT switch to the CASSETTE position. If your
system is not equipped with this switch, set the S register to octal
30000. If the AMP-generated area of the program is to be protected,
set the S register to 34000.
9. Press STORE.
10. Press PRESET.
11. Press BBL.
12. Wait for the READ FROM TAPE indicator to turn on. After a short
delay the DATA OUT indicator turns on.
Wait for tape motion to stop. Both indicators should be off.
Loading Series 8200 CNC
Executive Programs and PAL
Binary Programs
