Operation
Chapter 4
425
4. Insert the data cartridge into the recorder.
5. Wait for the recorder to complete the repacking operation.
NOTE: If the recorder is turned off while a rewind operation is in
progress, the data on the tape will be altered.
The following procedures assume that all information to be loaded is
contained on a data cartridge.
6. Load the executive program into the 8200 CNC using the procedures
outlined in Loading Series 8200 CNC Executive Programs and PAL
Binary Programs. Set the DATA SELECT switch to the CASSETTE
position. If your system is not equipped with this switch, set the
S-register to 34000 (octal).
7. Wait for tape motion to stop. Both the READ FROM TAPE and
DATA OUT indicators should be off. After a successful program
load, the 8200 processor switch panel will display 102077 (octal).
Do not press the RUN button.
8. Place the AMP utility program into the cartridge recorder.
9. Wait for the recorder to complete the repacking operation .
10. Halt the processor.
11. Set the S-register to 34000.
12. Press STORE.
13. Push PRESET.
14. Press BBL.
15. Wait for tape motion to stop. Both the READ FROM TAPE and
DATA OUT indicators should be off. After a successful program
load, the 8200 CNC processor switch panel will display 102077
(octal).
16. Press RUN. The AMP utility program will begin execution.
NOTE: When you have completed entering the AMP parameters into the
control, the composite executive can be loaded onto the data cartridge
using the procedures outlined in Loading PLC Programs.
1. Install the recorder as described in chapter 3.
Load Diagnostics From
Cartridge to 8200 CNC
