Installation
PLC programmable controllers connect directly to the data cartridge
recorder. Other Allen-Bradley products connect to an Industrial Terminal
System (cat. no. 1770-T1,-T2,-T3,-T4), or a 1770-T12 programmer which
provides the interface with the recorder. This section describes both types
of installation. Table 3.A shows the cables used to connect the recorder to
other Allen-Bradley products.
Table 3.A
Cables
for Connecting the Data Cartridge Recorder to Other AllenBradley Products
Product Connected to
the Data Cartridge
Recorder Cable Cat. No.
PLC Cassette Recorder Interconnect Cable 1774TD
Industrial T erminal
System
Digital Cassette Recorder Cable 1772TH
PLC4 Microtrol Digital Cassette Recorder Cable 1772TH
Digital Cassette
Recorder
Digital Cassette Recorder Cable 1772TH
PLC4 Microtrol Digital Cassette Recorder Cable 1772TH
Series 8200 CND Cassette Recorder Interconnect Cable 8200CS
Use the following procedure to connect the recorder to PLC
programmable controllers (Figure 3.1).
1. Connect the power cable between the recorder and a grounded 115V
AC outlet.
NOTE: If the recorder has been converted to 230V AC operation, use a
230V AC outlet.
2. Connect a Cassette Recorder Interconnect Cable (cat. no. 1774-TD)
between the recorder and the PLC programmable controller.
Connect the end labeled CASSETTE to the connector labeled A-B
CONTROLLER EQUIPMENT on the recorder. Connect the 41-pin
connector to the Program Panel Interface Module (cat. no. 1774-TB,
-TB2) or the On-line Programming Module (cat. no. 1774-TL2).
General
Connection to PLC
Programmable Controllers
