Operation
Chapter 4
43
Figure 4.1
Error
Indicator
10860I
8. Wait for the RECORD ON TAPE indicator to turn on, then off.
9. Press the STOP/REWIND pushbutton.
10.Wait for the tape to completely rewind.
11.Press the READ FROM TAPE pushbutton.
12.Wait for tape motion to stop.
13.If the ERROR indicator (Figure 4.2) on the program panel interface
module or the on-line programming module illuminates, repeat the
record operation.
14.When finished recording, remove the data cartridge and position the
record protect tab to the right.
Use the following procedure to load a recorded program into PLC
memory.
1. Install the recorder as described in chapter 3.
2. Set the BAUD RATE switch to 1200 baud. Select the track
containing the desired program.
3. Set the power ON/OFF switch on the ON position.
4. Insert a data cartridge into the recorder.
Loading PLC Programs
