Operation
Chapter 4
412
Use the following procedure to load a recorded program into PLC-4
Microtrol memory:
1. Install the recorder as described in chapter 3.
2. Set the BAUD RATE switch to 1200 baud. Select the track
containing the desired program.
3. Set the power ON/OFF switch to the ON position.
4. Insert a data cartridge into the recorder.
5. Wait for the recorder to complete the repacking operation .
6. Type [AUX FUNC] 41 on the 1770-T12 programmer.
7. Wait until the 1770-T12 programmer displays the message:
TAPE LOADING
COMPLETE
8. Type [CLEAR] on the 1770-T12 programmer to terminate the load
function.
Loading PLC4 Microtrol
Programs
