Operation
Chapter 4
418
Transferring Part Programs to Memory
Use the following procedure to load a recorded program into the Series
8200 CNC’s memory:
1. Install the recorder as described in chapter 3.
2. Set the BAUD RATE switch to 9600 baud. Select the track
containing the desired program.
3. Set the power ON/OFF switch to the ON position.
4. Insert a data cartridge into the recorder.
5. Wait for the recorder to complete the repacking operation.
NOTE: If the recorder is turned off while a tape rewind operation is in
progress, the data on the tape will be altered.
6. Select the KYBD (keyboard) mode.
7. Enter the following command through the keyboard; CS, CA, name].
“Name” is the program name the program is to be stored under in
memory.
8. Wait for the READ FROM TAPE indicator to turn on. After a short
delay the DATA OUT indicator turns on.
Wait for tape motion to stop. Both indicators should be off.
NOTE: If the recorder stops unexpectedly and either the DATA OUT or
READ FROM TAPE indicator is on in addition to the ERROR indicator
turn the recorder off and then on again. Press the READER RESET key.
Repeat the loading operation.
9. If the error indicator turns on during program transfer, program data
has been altered. you must repeat the loading operation.
Transferring Part Programs to a Tape Punch
Use the following procedure to transfer a recorded program from a
recorder to a tape punch:
1. Install the recorder as described in chapter 3.
2. Set the BAUD RATE switch to 9600 baud. Select the track
containing the desired program.
3. Set the power ON/OFF switch to the ON position.
4. Insert the data cartridge into the recorder.
