Page #149 background imageLoading...
Page #149 background image
Rockwell Automation Publication 5000-UM005B-EN-P - November 2015 149
Module Tag Definitions Appendix B
Chxx.FieldPowerOff BOOL Field power is not present at the channel.
Field power is provided through the SA power connector on the 5069-
AEN2TR EtherNet/IP adapter or a 5069-FPD field potential distributor.
0 = Field Power is present
1 = Field Power is not present
Chxx.Underrange BOOL Indicates the channel data is beneath the underrange threshold for this
channel.
For example, when the channel operates in the 4…20 mA input range, the
underrange threshold on the channel is
< 3.0 mA. If the input signal is 0
mA, this tag is set to 1.
0 = Channel data is not beneath
the underrange threshold
1 = Channel data is beneath the
underrange threshold
Chxx.Overrange BOOL Indicates the channel data is above the overrange threshold for this channel.
For example, when the channel operates in the 4…20 mA input range, the
overrange threshold on the channel is > 23.0 mA. If the input signal is
24 mA, this tag is set to 1.
0 = Channel data is not above
the overrange threshold
1 = Channel data is above the
overrange threshold
Chxx.LLAlarm BOOL Triggered when the input data value is less than the Low Low alarm value.
If latched, this alarm remains triggered until unlatched or if the input data
value is within Deadband.
0 = Alarm is not triggered
1 = Alarm is triggered
Chxx.LAlarm BOOL Triggered when the input data value is less than the Low alarm value.
If latched, this alarm remains triggered until unlatched or if the input data
value is within Deadband.
0 = Alarm is not triggered
1 = Alarm is triggered
Chxx.HAlarm BOOL Triggered when the input data value is greater than the High alarm value.
If latched, this alarm remains triggered until unlatched or if the input data
value is within Deadband.
0 = Alarm is not triggered
1 = Alarm is triggered
Chxx.HHAlarm BOOL Triggered when the input data value is greater than the High High alarm
value.
If latched, this alarm remains triggered until unlatched or if the input data
value is within Deadband.
0 = Alarm is not triggered
1 = Alarm is triggered
Chxx.RateAlarm BOOL Triggered when the change between consecutive channel samples divided
by the period of time between when the samples were taken exceeds the
Rate Alarm.
If latched, this tag remains set until it is unlatched.
0 = Alarm is not triggered
1 = Alarm is triggered
Chxx.CalFault BOOL Indicates the last attempted Calibration for this channel failed.
This tag is cleared, that is, set to 0, when power is cycled to the module.
0 = Calibration did not fail
1 = Calibration failed
Chxx.Calibrating BOOL Indicates the channel is currently being calibrated. 0 = Channel is not being
calibrated
1 = Channel is being calibrated
Chxx.CalGoodLowRef BOOL Indicates that a valid Low Reference signal has been sampled on this
channel.
IMPORTANT: This tag is available only when you use the Data with
Calibration connection type in the Module Definition. If you use the Data
connection type, this tag does not appear in the module tags.
For more information on how to define a module, see
Module Definition on
page 89
0 = Valid Low Reference signal
has not been sampled on this
channel
1 = Valid Low Reference signal
has been sampled on this
channel
Table 34 - 5069-IY4 Module - Input Tags
Name Size Definition Valid Values
