Rockwell Automation Publication 5000-UM005B-EN-P - November 2015 51
Chapter 4
Current/Voltage/Temperature-sensing Analog
Input Module Features (5069-IY4)
The 5069-IY4 input module has four differential, non-isolated channels. Each
channel supports connection to the following input types:
Current
Vo l t age
RTD
Thermocouple
Differential inputs have a greater resistance to the effects of electromagnetic noise
and provide improved flexibility regarding cable length when wiring your
module.
Topic Page
Module Features 52
Fault and Status Reporting 71
IMPORTANT
Remember the following:
This module also has features that apply to all 5069 Compact I/O™ analog I/
O modules that are described in Chapter 2,
Common Analog I/O Module
Features on page 25.
You can configure the features that are described in this chapter with the
Logix Designer application.
For more information on how to configure the module, see Chapter 6,
Configure the Module on page 83.
