Allen-Bradley CENTERLINE User Manual

Publication 2100-IN012B-EN-P - April 2005
1-8 General Information
Table 1.C 2400 Units
2400 Units
Series
Letter
Scope Description of Change Date Implemented
in U.S.
A — Original design June 1990
B 18A, 24A, 30A Changed to Series B, Bulletin 194R, 30A disconnect March 1992
C 18A, 24A, 30A Changed to three Bulletin 800E pilot devices on 0.5 space factor units July 1992
D
All sizes New disconnect external auxiliary contacts and new 600A-1200A circuit breaker operating mechanism February 1996
16A-85A Original design of units with a Bulletin 100-C contactor September 1999

Allen-Bradley CENTERLINE Specifications

General

Short Circuit Current Rating (SCCR)	Up to 100kA
Modular Design	Yes
Type	Motor Control Center (MCC)
Voltage	Up to 600V AC
Communication Protocols	EtherNet/IP, DeviceNet
Enclosure Type	NEMA 1, NEMA 3R, NEMA 4, NEMA 4X, NEMA 12
Standards Compliance	UL 845, IEC 61439
