1 Publication 2100-IN012B-EN-P—April 2005
Chapter
12
Parts Illustrations
Typical Section Construction
Lifting Angle
Top Horizontal
Wireway Baffle
Top Horizontal
Wireway Cover
Right Hand Unit Support
Vertical Wireway Assembly
Bus Splice Access Cover
Section Nameplate
Vertical Wireway Door
Vertical to Horizontal Bus
Connection Access Cover
Vertical Bus Support Cover
Unit Support Pan
Sealing Strap
Top and Bottom
Bottom Support Angle
Bottom Horizontal
Wireway Cover
Left Hand
Bottom End Closing Plate
Horizontal Ground Bus
Top or Bottom
Left Hand Side Plate Assembly
Vertical Plug-in
Ground Bus
Left Hand
Center End Plate
Horizontal Power Bus
Vertical Power Bus
Horizontal and Vertical
Bus Support
Left Hand
Top End Closing Plate
Removable Top Plate
