1 Publication 2100-IN012B-EN-P—April 2005
Chapter
5
Installing and Removing Plug-In Units
Installing Plug-In Units
For unit installation, refer to publication 2100-IN014x-EN-P, Installing Units
with Vertical Operating Handles, and publication 2400-IN007x-EN-P, Installing
Units with Horizontal Operating Handles.
Removing Plug-In Unit with
a Vertical Operating Handle
from a Section
Figure 5-1 Opening a Unit Door with a Vertical Operating Handle
1. Make sure disconnect handle is in the OFF/O position.
2. Turn door latches 1/4 turn.
3. Open door completely.
ATTENTION
Review your company safety lockout and tag-out
procedure.
De-energize all units before installing or removing.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Allen-Bradley CENTERLINE and is the answer not in the manual?

Allen-Bradley CENTERLINE Specifications

General IconGeneral
Short Circuit Current Rating (SCCR)Up to 100kA
Modular DesignYes
TypeMotor Control Center (MCC)
VoltageUp to 600V AC
Communication ProtocolsEtherNet/IP, DeviceNet
Enclosure TypeNEMA 1, NEMA 3R, NEMA 4, NEMA 4X, NEMA 12
Standards ComplianceUL 845, IEC 61439
