Publication 2100-IN012B-EN-P - April 2005
7-6 Operator Handle and Unit Interlock
Figure 7.7 Locking Small Handle in ON/I POSITION, Vertical Operating Handle
Figure 7.8 Locking Medium Handle in ON/I Position
Drill Out
Drill Out
