Rockwell Automation Publication 2080-UM002G-EN-E - March 2015 165
Specifications Appendix A
Wire size 0.2…2.5 mm
2
(24…12 AWG) solid copper wire or
0.2…2.5 mm
2
(24…12 AWG) stranded copper wire
rated @ 90 °C (194 °F ) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
Wire type Use Copper Conductors only
Terminal screw torque 0.6 Nm (4.4 lb-in) max
(using a 2.5 mm (0.10 in.) flat-blade screwdriver)
Input circuit type 12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type Relay 24V DC sink (standard and high-
speed)
24V DC source (standard and high-
speed)
Event input interrupt support Yes
Power consumption 12.32 W
Power supply voltage range 20.4…26.4V DC Class 2
I/O rating Input 24V DC, 8.8 mA
Output 2 A, 240V AC, general use
Input 24V DC, 8.8 mA
Output 24V DC, Class 2, 1 A per point (Surrounding air temperature 30 °C)
24 V DC, Class 2, 0.3 A per point (Surrounding air temperature
65 °C)
Isolation voltage 250V (continuous), Reinforced Insulation
Type, Outputs to Aux and Network, Inputs
to Outputs
Type tested for 60 s @ 720V DC, Inputs to
Aux and Network, 3250 V DC Outputs to
Aux and Network, Inputs to Outputs
50V (continuous), Reinforced Insulation Type, I/O to Aux and Network, Inputs
to Outputs
Type tested for 60 s @ 720V DC, I/O to Aux and Network, Inputs to Outputs
Pilot duty rating C300, R150 (2080-LC30-24QWB only) —
Insulation stripping length 7 mm (0.28 in.)
Enclosure type rating Meets IP20
North American temp code T4
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
General Specifications – 2080-LC30-24QWB, 2080-LC30-24QVB, 2080-LC30-24QBB
Attribute 2080-LC30-24QWB 2080-LC30-24QVB 2080-LC30-24QBB
Inputs
Attribute High-Speed DC Input
(Inputs 0…7)
Standard DC Input
(Inputs 8 and higher)
Number of Inputs 8 6
Voltage category 24V DC sink/source
Operating voltage range 16.8…26.4V DC 10…26.4V DC
Off-state voltage, max 5V DC
Off-state current, max 1.5 mA
On-state current, min 5.0 mA @ 16.8V DC 1.8 mA @ 10V DC
On-state current, nom 8.8 mA @ 24V DC 8.5 mA @ 24V DC
On-state current, max 12.0 mA @ 30V DC
