166 Rockwell Automation Publication 2080-UM002G-EN-E - March 2015
Appendix A Specifications
Nominal impedance 3 kΩ 3.74 kΩ
IEC input compatibility Type 3
AC input filter setting 8 ms for all embedded inputs
(In Connected Components Workbench, go to the Embedded I/O
configuration window to re-configure the filter setting for each input
group)
Isolated AC Inputs (2080-LC30-24QWB, 2080-LC30-24QVB, 2080-LC30-24QBB)
(Inputs 0…7)
Attribute Value
On-state voltage, nom 12/24V AC @ 50/60 Hz
Off-state voltage, min 4V AC @ 50/60Hz
Operating frequency, nom 50/60 Hz
Inputs
Attribute High-Speed DC Input
(Inputs 0…7)
Standard DC Input
(Inputs 8 and higher)
Outputs
Attribute 2080-LC30-24QWB 2080-LC30-24QVB / 2080-LC30-24QBB
Relay Output Hi-Speed Output
(Outputs 0…1)
Standard Output
(Outputs 2 and higher)
Number of outputs 10 2 8
Output voltage, min 5V DC, 5V AC 10.8V DC 10V DC
Output voltage, max 125V DC, 265V AC 26.4V DC 26.4V DC
Load current, min 10 mA
Load current, max 2.0 A 100 mA (high-speed operation)
1.0 A @ 30 °C
0.3 A @ 65 °C (standard operation)
1.0 A @ 30 °C
0.3 A @ 65 °C (standard operation)
Surge current, per point Refer to Relay Contacts Ratings
on page 166
4.0 A every 1 s @ 30 °C; every 2 s @ 65 °C
(1)
Current, per common, max 5 A — —
Turn on time/
Turn off time, max
10 ms 2.5 μs 0.1 ms
1 ms
(1) Applies for general purpose operation only. Does not apply for high-speed operation.
Relay Contacts Ratings
Maximum Volts Amperes Amperes
Continuous
Volt-Amperes
Make Break Make Break
120V AC 15 A 1.5 A 2.0 A 1800V A 180V A
240V AC 7.5 A 0.75 A
24V DC 1.0 A 1.0 A 28V A
125V DC 0.22 A
