Allen-Bradley Micro830

Rockwell Automation Publication 2080-UM002G-EN-E - March 2015 247
Troubleshooting Appendix E
0xF005 The user program failed an integrity check while
the Micro800 controller was in Run mode.
Perform one of the following:
• Cycle power on your Micro800 controller. Then, download your program
using Connected Components Workbench and start up your system.
• Refer to the Wire Your Controller
on page 35.
0xF006 The user program is incompatible with the
Micro800 controller’s firmware revision.
Perform one of the following:
• Upgrade the Micro800 controller’s firmware revision using ControlFlash.
• Contact your local Rockwell Automation technical support representative for
more information about firmware revisions for your Micro800 controller. For
more information on firmware revision compatibility, go to
http://www.rockwellautomation.com/support/firmware.html
0xF010 The user program contains a function/function
block that is not supported by the Micro800
controller.
Perform the following:
1. Modify the program so that all functions/function blocks are supported by
the Micro800 controller.
2. Build and download the program using Connected Components Workbench.
3. Put the Micro800 controller into Run mode.
0xF014 A memory module memory error occurred. Reprogram the memory module. If the error persists, replace the memory
module.
0xF015 An unexpected software error occurred. Perform the following:
1. Cycle power on your Micro800 controller.
2. Build and download your program using Connected Components Workbench,
and then reinitialize any necessary data.
3. Start up your system.
4. Refer to the Wire Your Controller
on page 35.
0xF016 An unexpected hardware error occurred. Perform the following:
1. Cycle power on your Micro800 controller.
2. Build and download your program using Connected Components Workbench,
and then reinitialize any necessary data.
3. Start up your system.
4. Refer to the Wire Your Controller
on page 35.
OxF019 An unexpected software error occurred due to
memory or other controller resource issue.
Perform the following:
1. Cycle power on your Micro800 controller.
2. Build and download your program using Connected Components Workbench,
and then reinitialize any necessary data.
3. Start up your system.
0xF020 The base hardware faulted or is incompatible
with the Micro800 controller’s firmware revision.
Perform one of the following:
• Upgrade the Micro800 controller’s firmware revision using ControlFlash.
• Replace the Micro800 controller.
• Contact your local Rockwell Automation technical support representative for
more information about firmware revisions for your Micro800 controller. For
more information on firmware revision compatibility, go to
http://www.rockwellautomation.com/support/firmware.html
0xF021 The I/O configuration in the user program is
invalid or does not exist in the Micro800
controller.
Perform the following:
1. Verify that you have selected the correct Micro800 controller from the Device
Toolbox.
2. Correct the plug-in I/O module configuration in the user program to match
that of the actual hardware configuration.
3. Recompile and reload the program.
4. Put the Micro800 controller into Run mode.
If the error persists, be sure to use Connected Components Workbench
programming software to develop and download the program.
List of Error Codes for Micro800 controllers
Error Code Description Recommended Action
