248 Rockwell Automation Publication 2080-UM002G-EN-E - March 2015
Appendix E Troubleshooting
0xF022 The user program in the memory module is
incompatible with the Micro800 controller’s
firmware revision.
Perform one of the following:
• Upgrade the Micro800 controller’s firmware revision using ControlFlash to be
compatible with the memory module.
• Replace the memory module.
• Contact your local Rockwell Automation technical support representative for
more information about firmware revisions for your Micro800 controller. For
more information on firmware revision compatibility, go to
http://www.rockwellautomation.com/support/firmware.html
0xF023 The controller program has been cleared. This
happened because:
• a power down occurred during program
download or transfer from the memory
module.
• the Flash Integrity Test failed (Micro810 only).
Download or transfer the program.
0xF050 The embedded I/O configuration in the user
program is invalid.
Perform the following:
1. Correct the embedded I/O configuration in the user program to match that of
the actual hardware configuration.
2. Build and download the program using Connected Components Workbench.
3. Put the Micro800 controller into Run mode.
If the error persists, be sure to use Connected Components Workbench
programming software to develop and download the program.
0xF100 There is general configuration error detected in
the motion configuration downloaded from the
Connected Components Workbench software,
such as number of axis, or motion execution
interval being configured out of range.
Perform the following:
• Correct the axes configuration in the user program.
If fault is consistent, upgrade to the latest software revision of Connected
Components Workbench.
See Motion Axis Configuration in Connected Components Workbench
on
page 95.
0xF110 There is motion resource missing, such as
Motion_DIAG variable not defined.
Perform the following:
• Correct the axes configuration in the user program.
If fault is consistent, upgrade to the latest Connected Components Workbench
software revision.
See Motion Axis Configuration in Connected Components Workbench
on
page 95.
0xF12z
(Note: z indicates
the logic axis ID.)
Motion configuration for axis z cannot be
supported by this controller model, or the axis
configuration has some resource conflict with
some other motion axis, which has been
configured earlier.
Perform the following:
• Remove all axes and re-configure motion with the guidance from the User
Manual.
If fault is consistent, upgrade to the latest Connected Components Workbench
software revision.
0xF15z
(Note: z indicates
the logic axis ID.)
There is a motion engine logic error (firmware
logic issue or memory crash) for one axis
detected during motion engine cyclic operation.
One possible reason can be motion engine data/
memory crash.
Perform the following:
1. Clear the fault, and switch the controller to RUN mode again.
2. If fault is consistent, do power cycle for whole motion setup, including
controller, drive and moving mechanism.
3. Re-download the User Application.
0xF210 The expansion I/O terminator is missing. Perform the following:
1. Power off the controller.
2. Attach the expansion I/O terminator on the last expansion I/O module on the
system.
3. Power on the controller.
List of Error Codes for Micro800 controllers
Error Code Description Recommended Action
To Next Page
