198 Rockwell Automation Publication 2080-UM002K-EN-E - March 2019

Chapter 10 Using microSD Cards

5. On the Block Selector window that appears, type DLG to filter the DLG

function block from the list of available function blocks. Click OK.

6. Create the following local variables for your project.

Local Variables

Variable Name Data Type

EnDlg BOOL

cfg_id USINT

data_time_enable BOOL

error UDINT

status USINT

data_bool BOOL

data_int8 INT

data_string STRING
