Output Override and I/O Update Instructions
Chapter 7
717
Table 7.C
Average
Execution Times in Microseconds for FILET
OFILE AND, OR,
XOR Instructions when Instruction is T
rue
Rate Per Scan Dist. Complete Mode Complete Mode
5
10
15
25
50
100
256
512
174
223
272
370
615
1105
2648
5171
148
197
246
344
589
1079
2622
5145
Formula for more exact approximations can be found in Section C.6.
Execution Time for incremental mode is 100 microseconds per scan.
When FALSE, execution time is 17.6 microseconds.
Table 7.D
The
Following Instructions Reset the W
atchdog T
imer
FileToFile Move
WordToFile Move
FileToWord Move
FileToFile AND, OR, XOR
WordToFile AND, OR, XOR
File Complement
File Search
File Diagnostic
Return
End
T.End
SBR
Sequencer In
Sequencer Out
Sequencer Load
Fifo Load
Fifo Unload
Shift File Up
Shift File Down
Shift Bit Left
Shift Bit Right
Block Transfer (for processors equipped with cat. no. 1772LG, processor module, Rev. J firmware
or later)
