File Search and File Diagnostic Instructions
Chapter 17
173
Figure 17.2
FILE
SEARCH Format
FILE
SEARCH
COUNTER ADDR:
030
POSITION: 000
FILE LENGTH: 001
WORD ADDR:
011
FILE: 110-110
030
(EN)
17
Numbers
shown are default values. Bold numbers must be replaced by userentered values. The number of default address digits
initially displayed  3, 4, or 5  will depend on the size of the data table. Initially displayed default values are governed by the I/O rack
configuration.
COUNTER ADDRESS
:
Address of the instruction in the accumulated value area of the data table.
POSITION :
Current word being operated upon (accumulated value of counter).
FILE LENGTH :
Number of words in file (preset value of the counter).
WORD ADDRESS
:
Address of input word to be matched.
FILE :
Starting address of data file to be searched.
030
(DN)
15
Figure 17.3 shows the format of Figure 17.2 after the conditions listed
below have been entered:
COUNTER ADD – 200
FILE LENGTH – 64
WORD ADDR – 141
FILE – Starts at word 400, ends at word 477
The procedure for using the data monitor mode for data entry or monitor is
presented in Chapter 12.
