Data Transfer File Instructions
Chapter 12
1222
Table 12.B
Accessing
the Display
1
Key Sequence Explanation
[DISPLAY] X Accesses data monitor format.
[DISPLAY] X [RECORD]
2
Prints first 20 lines of the data monitor.
[DISPLAY] X [HELP]
2
Accesses the ASCII/Hexadecimal conversion table.
[DISPLAY] X [HELP]
[RECORD]
2
Prints the ASCII/Hexadecimal conversion table.
where X = 0 - Binary Data Monitor, 1 - Hexadecimal Data Monitor, 2 - ASCII Data Monitor
2
1
The cursor must be positioned on the file instruction in the ladder diagram.
2
Requires Series B, Revision F (or later) keyboard.
Once pressed, the industrial terminal display will change from ladder
diagram to data monitor mode. An example file instruction and its
corresponding data monitor display in hexadecimal format are shown in
Figure 12.20.
