Report Generation
Chapter 9
910
Table 9.E
Industrial
Terminal Control Codes
Control Code Key Sequence Function
[CTRL] [P]
[Column #] [;] [Line #] [A]
Positions the cursor at the specified column and line number.
[CTRL] [P] [A] will position the cursor at the top left corner of the
screen.
[CTRL] [P] [F] Moves the cursor one space to the right.
[CTRL] [P] [U] Moves the cursor one line up in the same column.
[CTRL] [P] [5] [C] Turns cursor ON.
[CTRL] [P] [4] [C] Turns cursor OFF.
[CTRL] [P] [5] [G] Turns ON graphics capability.
[CTRL] [P] [4] [G] Turns OFF graphics capability.
[CTRL] [P] [5] [P] Turns Channel C Outputs ON.
[CTRL] [P] [4] [P] Turns Channel C Outputs OFF.
[CTRL] [I] Horizontal tab that moves the cursor to the next preset 8th
position.
[CTRL] [K] Clears the screen from cursor position to end of screen and
moves the cursor to the top left corner of the screen.
Key Sequence Attribute
1
[CTRL] [P] [0] [T] Attribute 0 = Normal Intensity
[CTRL] [P] [1] [T] Attribute 1 = Underline
[CTRL] [P] [2] [T] Attribute 2 = Intensify
[CTRL] [P] [3] [T] Attribute 3 = Blinking
[CTRL] [P] [4] [T] Attribute 4 = Reverse Video
1
Any three attributes can be used at one time using the following key sequence: [CTRL] [P] [Attribute #] [;] [Attribute #] [;]
[Attribute #] [T].
