Addressing
Appendix A
A5
Using 8Point I/O Modules
Figure A.3
Illustration
of 2slot Addressing with 8point Input and Output Modules
17 16 15 14 13 12 11 10 07 06 05 04 03 02 01 00
Input
Terminals
Output
Terminals
17 16 15 14 13 12 11 10 07 06 05 04 03 02 01 00
Output
image table word corresponding
to the I/O group.
Used Output bits
Input image table word corresponding
to the I/O group.
00
01
02
03
04
05
06
07
10
11
12
13
14
15
16
17
I/O Module
Group
Unused Output bits
Unused Input bits
Used Input bits
