T064 [Relay 2 Off Time] 0.0/600.0 Secs 0.1 Secs 0.0 Secs
T065 [Opto Out Sel] 0/17 0 = “Ready/Fault”
1 = “At Frequency”
2 = “MotorRunning”
3 = “Hand Active”
4 = “Motor Overld”
5 = “Ramp Reg”
6 = “Above Freq”
7 = “Above Cur”
8 = “Above DCVolt”
9 = “Above Anlg 2”
10 = “Above PF Anlg”
11 = “Anlg In Loss”
12 = “ParamControl”
13 = “Retries Exst”
14 = “NonRec Fault”
15 = “Reverse”
16 = “Logic In 1”
17 = “Logic In 2”
1
T066 [Opto Out Level] 0.0/9999 0.1 0.0
T068 [Opto Out Logic] 0/1 1 0
T069 [Analog In 1 Sel] 0/6 1 2
T070
T074
[Analog In 1 Lo]
[Analog In 2 Lo]
0.0/100.0% 0.1% 0.0%
T071
T075
[Analog In 1 Hi]
[Analog in 2 Hi]
0.0/100.0% 0.1% 100.0%
T072
T076
[Analog In 1 Loss]
[Analog In 2 Loss]
0/6 0 = “Disabled”
1 = “Fault (F29)”
2 = “Stop”
3 = “Zero Ref”
4 = “Min Freq Ref”
5 = “Max Freq Ref”
6 = “Int Freq Ref”
0
T073 [Analog In 2 Sel] 0/7 1 2
T077 [Sleep-Wake Sel] 0/3 0 = “Disabled”
1 = “Analog In 1”
2 = “Analog In 2”
3 = “Command Freq”
0
T078 [Sleep Level] 0.0/100.0% 0.1% 10.0%
T079 [Sleep Time] 0.0/600.0 Secs 0.1 Secs 0.0 Secs
T080 [Wake Level] 0.0/100.0% 0.1% 15.0%
T081 [Wake Time] 0.0/600.0 Secs 0.1 Secs 0.0 Secs
No. Parameter Min/Max Display/Options Default
T065 Setting T066 Min/Max
6 0/400 Hz
7 0/180%
8 0/815 Volts
9 0/100%
10 1/180 degs
12 0/1
T068 Option Opto Out Logic
0 NO (Normally Open)
1 NC (Normally Closed)
T069 Option Setting Input Range DIP Switch AI1 Setting
0 Current Mode 0-20 mA 0-10V
1 Current Mode 4-20 mA 0-10V
2 Voltage Mode - Unipolar 0-10V 0-10V
4 Current Mode (Square Root) 0-20 mA 0-10V
5 Current Mode (Square Root) 4-20 mA 0-10V
6 Voltage Mode - Unipolar (Square Root) 0-10V 0-20 mA
T073 Option Setting Input Range DIP Switch AI1 Setting
0 Current Mode 0-20 mA 20 mA
1 Current Mode 4-20 mA 20 mA
2 Voltage Mode - Unipolar 0-10V 10V
3 Voltage Mode - Bipolar -10 to +10V 10V
4 Current Mode (Square Root) 0-20 mA 20 mA
5 Current Mode (Square Root) 4-20 mA 20 mA
6 Voltage Mode - Unipolar (Square Root) 0-10V 10V
7 Voltage Mode - Bipolar (Square Root) -10 to +10V 10V
WWW.KORATGROUP.COM

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
